Categories | Laser Scanning Radar |
---|---|
Brand | DADISICK |
Model | LD-05D Series |
Laser Wavelength: | 905 nm |
Eye-Safe Level: | Class I |
Working Range: | 0.05 m - 5 m |
Scan Angle Range: | 270° |
Measurement Accuracy: | ±3 mm |
Angular Resolution: | 0.1° / 0.3° |
Scanning Frequency: | 15 Hz / 30 Hz |
Update Time | Oct 30,2024 |
Basic Information
|
||
Product name
|
Two-dimensional TOF obstacle avoidance LiDAR |
|
Product model
|
LD-05DN | LD-05DP |
Work area | 0.05 m ~ 5 m | |
I/O output | NPN | PNP |
Features
|
||
Laser source
|
905 nm (class I) |
|
Scan angle range
|
270° |
|
Scanning frequency | 15 Hz / 30 Hz | |
Angular Resolution | 0.1° / 0.3° | |
Work area | 0.05 m ~ 5 m | |
Self-learning function | Automatic environment scanning, generating area |
Mechanical/electronic parameters
|
||
Electrical connections
|
DB15 MALE / SCATTER |
|
Supply voltage
|
DC 9 V ~ 28 V |
|
Power consumption
|
2 W |
|
Switch drive
|
DC 30 V 50 mA MAX |
|
Shell color | Yellow | |
Protection level | IP65 | |
Weight | 150 g, no cable | |
Size (length × width × height) | 50 mm × 50 mm × 76 mm |
Performance
|
||
Recognizable object shape
|
Almost any shape |
|
Measurement error
|
±3 mm |
|
Number of regional groups
|
16 regional groups, each containing 3 regions |
Interface
|
||
USB
|
Micro - USB |
|
Input
|
GND/NC × 4 |
|
Switch output
|
NPN × 3, device working status indication × 1 |
|
Signal output hold time
|
100 ms ~ 10,000 ms (adjustable) typical value 330 ms |
|
Response time | 15 Hz: 67 ms ~ 29,949 ms (adjustable) typical value 134 ms 30 Hz: 33 ms ~ 29,997 ms (adjustable) typical value 66 ms | |
Status Indicator | Status indicator × 1, area group indicator × 3 |
Environmental parameters
|
||
Vibration resistant
|
10-55 Hz, amplitude 0.75 mm, XYZ three-axis,2 hours per axis; 50-200 Hz, 196 m/s² (20G), scanning speed 2 min/cycle, XYZ three-axis,2 hours per axis |
|
Working temperature
|
-10℃ ~ +55℃ |
|
Storage temperature range
|
-30℃ ~ +75℃ |
|
Resistance to ambient light | >15,000 lux |
